Technical data:
Type: CSM 1, CSM 2, CSM 3, CSM 4
Lenght: 22 630 mm
Weight: 24 050 kg
Body:
Framework: steel
Lenght: 21 747 mm
Width: 2311 mm
Wheel-base:
A–B: 3800 mm, B–C: 6880 mm
Wheel diameter: 780 mm
Spring type: A9
Seats: 28
Stands (5 pers./m2):
127
Standing area: 25,43 m2
Capacity: 155 person
Door:
Type: double 'pleat'
Layout: 2–2–2,
and 2–2–2–2–2
Operation: by compressed air
Engines:
Quantity: 2
Type: TR 4,5/14
Power: 58,8 kW
Brakes:
Normal: electric brake
Additional: 4-trunk battery powered
magnetic rail-brake
Stop: compressed air-brake,
hand-brake
Air-compressor:
Type: CL2
Operation: by electrical motor
Electrification system: 600V DC
Lights: bulbs, 600V DC
Type of control: manual, direct switch
|
