Fleet data:

Built: 1948, 1956--57, 1957--58,1959--61,1962--65
Fleet Numbers: 3700--3701, 3200--3249, 3250--3349, 3350--3474, 3800--3899
Numbers Currently operational: 252 for service + 4 driver trainers
Routes served: 19, 41, 42, 47, 49, 50, 52, 62, 69

Technical data:

Type classification: UV prototype, UV1, UV2, UV3, UV5
Lenght: 13 500 mm, 13 690 mm
Weight: 19 750 kg
Axle Load (5 pers./m²): 7300 kg, 7418 kg
Adhesion proportion: 100 %
Bodywork:
Framework: steel
Lenght: 12 600 mm
Widht: 2300 mm
Height: 3100 mm
Floor height: 783 mm (at the end of car: 668 mm)
Wheelbase: 1600 mm
Distance between pivots: 5800 mm
Wheel diameter: 670 mm
Capacity:
Gross area: 25 m²
Number of Seats: 22 and 20
Standing room (5 passengers/m²): 72 and 74
Standing area: 13,9 m² and 14,9 m²
Total passenger capacity: 94 pers.
Doors:
Type: Sliding double
Layout: 2-1-2 or 2-2-2
Operated by compressed air
Motors:
Number: 4
Type: Ta 1,18
Power: 37 kW
Brakes:
Normal: electrical
Additional: 4-trunk battery powered magnetic rail-brake
Parking: compressed air-brake, hand-brake
Electrification system: 600 V DC
Lighting: bulbs, 24 V
Battery charger: Transformer motor (a few cars have static transformers)
Type of control: manual, contactors
Minimum curvature radius: 18 m
Maximum speed: 60 km/h

Additional data:

The protoype cars were formed from motor cars 3608 and 3652 (built 1941-42).

The original numbers of the Driver-training cars (changed in 1977):

3400-->7660, 3401-->7661, 3402-->7662, 3403-->7663
These originally had 2 drivers' cabs (except type 'UV5').

As of December 1993, 20 cars have been rebuilt as MUV types.

Lately, many UV cars have been withdrawn.

In 1962, UVs 3235--3258 were experimentally rebuilt as an articulated unit (3799, later renumbered 3729). In 1966 they were rebuilt as 2 separate cars again.

Pictures:

Click here for pictures of 'UV' type cars.

Created: 1993--94  Quantity: 20  Fleet Numbers: 3404, 3409, 3410, 3411, 3423, 3426, 3427, 3429, 3430, 3431, 3432, 3440, 3441, 3443, 3444, 3446, 3449, 3454, 3456, 3461 Home Depot: Száva kocsiszín

Main differences between MUV's and UV's:

Drivers' cabs: 2
Number of Seats: 28
Standing room: 56
Standing area: 11,3 m²
Total Passenger Capacity: 84 pers.
Park-break: Compressed air, combined with spring-force
Lighting: Fluorescent strip, 24V
Battery Charger: static transformer
Miscellanious: Enclosed drivers' cabs, heating, stepwell lighting
